Ports Panel
Thereceiverisequippedwiththefollowingports:
• USB–Usedforhigh‐speeddatatransferandcommunicationbetweenthereceiverandanexternaldevice.
• Power/Serial—Usedforcommunicationbetweenthereceiverandanexternaldevice.Alsousedtopowerthereceiver
whentheinternalbatteriesarenotinuse.See
“UsingInternalandExternalPowerSources”onpage25.
• CellularANTConnector—NotaGPSAntennaConnector.ATNCconnectorusedtoconnectthecellularandUHF
antenna.
Figure7:ReceiverPortsPanel
NeedPic
