20. CHANGING THE SETTINGS
114
2. To edit a target, select the desired target and
press [EDIT]. <Reflector/edit> is displayed.
Select/input relevant information for the target.
Reflector: Prism/Sheet/N-Prism
Const.: -99 to 99 mm
• When selecting "N-Prism" in "Reflector", prism
constant correction values are set to "0"
automatically.
3. Press [OK] in the screen of step 2 to save edited
information and return to <Reflector setting>.
Press [OK] to return to <EDM configurations>.
It is possible to allocate tabs in Observation mode and Menu mode to suit the measurement
conditions. It is possible to operate the OS efficiently because unique tab allocations can be preset to
suit various applications and the ways that different operators handle the instrument.
• The current tab allocations are retained until they are revised again, even when the power is cut off.
•Press [CLEAR] in <Customize/Select screen> to return all customized configurations including
screen controls, status bar/Starkey mode settings, and softkey allocations to their previous settings.
• One screen can contain a maximum of 5 tabs.
• When tab allocations are recorded and registered, the previously recorded tab settings are cleared.
Tab allocations
The following are tabs allocated when the OS was shipped and tabs that can be defined by the
user.
• "Basic observation"
• Setting out
20.4 Allocating User-defined Tabs
Factory settings User-definable tabs
SHV SHV
SHVdist SHVdist
Graphic SHV + Coord.
Factory settings User-definable tabs
Obs. Obs.
Graphic
To Next Page
