58
TROUBLE SHOOTING
OPERATING THE CHINREST MANUALLY IN THE CASE OF A MALFUNCTION
If the chinrest malfunctions, you can operate it manually.
Operate the chinrest manually only in an emergency.
Inform your dealer or TOPCON (at the address on the back cover) of the malfunction at once.
1 Turn off the switch and unplug the power cord from the outlet.
2 Remove the left cover (as viewed from the inspector side) with a screwdriver, etc.
3 Insert the emergency chinrest knob into the hole by turning it. Make sure that the emergency
chinrest knob is put into the hole properly.
4 Turn the emergency chinrest knob, and the chinrest moves up and down.
CAUTION
Before handling the chinrest manually in the case of a malfunction,
remove the power cord from the instrument. If not, your finger may be
pinched and injured by a wrong operation.
POWER
To Next Page
