Topcon TP-L6 Series User Manual

10
4. PRODUCT OUTLINE
4.1 Parts and Functions of the Instrument
Display
Operating keys
Handle
Remote control receiving window
Handle fixing screw
Upper laser emitting window
(TP-L6WGV/WAV only)
Lower laser emitting
window
(TP-L6WGV/WAV only)
Laser beam window
Laser beam emitted from
here
Grade axis mark
Laser grade starting point
Remote control
receiving window
Centerline LED
(TP-L6WG/WBG/WA/WB only)
Starting point of the laser line
Laser centerline mark
(TP-L6WG/WBG/WA/WB only)
Upper laser blocking hatch (TP-L6WGV/WAV only)
Blocks the upper laser beam by rotating
Battery holder
Battery holder knob
Self-centering feet
