18
5. USING THE BATTERY
Slots 1 and 2:
The battery charger can hold and charge up to two batteries at the same time.
Charging time per battery:
BDC72: about 8 hours (at 25°C)
(Charging can take longer than the times stated above when temperatures are either especially high or low.)
Charging lamp:
1. Turn the battery holder knob to the “Open” side until it stops.
2. Remove the battery holder.
LED Description
Green lamp flashing On charge
Green lamp lit Fully charged
Yellow lamp flashing Battery temperature is out of charging temperature range. Charge the battery
again within the charging temperature range. If the yellow lamp still does not stop
flashing, contact your local dealer.
Off The battery is not correctly mounted. Mount it again correctly. If the lamp is still
off, contact your local dealer.
Red lamp lit Charging is not being normally performed. There may be trouble with the charger
or battery. Contact your local dealer.
5.2 Installing the Battery
