Part II Wiring Installation Instruction
2.1 System Wiring Diagram
TL-A1
PC
+5V
LPWM
L-ON
WP
LASER
GND
OUTPUT-1
OUT1
+24V
GND
Wind
/SPI
AXIS-X
DIR-
PUL-
+5V
AXIS-Y
DIR-
PUL-
+5V
AXIS-Z/U
DIR-
PUL-
+5V
Lmt_Y+
GND
Lmt_X-
Lmt_X+
Lmt_Y-
INPUT
-1
+24V
+24V
GND
POWER
Lmt_Z/U-
Lmt_Z/U+
Door_SW
INPUT
-2
Foot_SW
+24V
GND
o
24V
0V
o
24V
0V
X Origin Limit
X Upper Limit
Y Origin Limit
Y Upper Limit
Protection
Foot Switch
Z/U Origin Limit
Z/U Upper Limit
IN G WP TL
Water
Protect
PUL+
PUL-
DIR+
DIR- PUL+
PUL-
DIR+
DIR- PUL+
PUL-
DIR+
DIR-
Wind / SPI Completion / Feeding / Laser / Press / Status / Pen/Nip Rolls
V-
DC24V/2A
V+
CO2 Laser
Power
Lift / Feeding
24V Relay
