2.4.9 Input Interface
INPUT-1
INPUT-2
Pin
Definition
1
+24V DC24V Output
2
Foot_SW Foot switch signal input, active on the rising edge, with pulse
width not less than 100ms
3
Door_SW Protection signal input, connecting to cover protection and
other signals
4
Lmt_Z/U+ Z/U upper limit, axis movement to the max coordinate limit
sensor input
5
Lmt_Z/U- Z/U origin limit, axis movement to the minimum coordinate (0)
limit sensor input sensor input
6
GND Power source grounding
Pin
Definition
1
+24V DC24V Output
2
Lmt_Y+ Y upper limit, axis movement to the max coordinate limit
sensor input
3
Lmt_Y- Y origin limit, axis movement to the minimum coordinate (0)
limit sensor input
4
Lmt_X+ X upper limit, axis movement to the max coordinate limit
sensor input
5
Lmt_X- X origin limit, axis movement to the minimum coordinate (0)
limit sensor input
6
GND Power source grounding
