2.3 Wiring Instruction
2.3.1 Interface Diagram
TL-A1
PC
+5V
LPWM
L-ON
WP
LASER
GND
OUTPUT-1
OUT1
+24V
GND
Wind
/SPI
AXIS-X
DIR-
PUL-
+5V
AXIS-Y
DIR-
PUL-
+5V
AXIS-Z/U
DIR-
PUL-
+5V
Lmt_Y+
GND
Lmt_X-
Lmt_X+
Lmt_Y-
INPUT
-1
+24V
+24V
GND
POWER
Lmt_Z/U-
Lmt_Z/U+
Door_SW
INPUT
-2
Foot_SW
+24V
GND
2.3.2 Wiring Diagram
2.3.2.1 Motor Wiring
The following is X axis motor wiring, other axis are similar.
1. Step Motor Wiring
