Part IV Rotary Cutting Machine
4.1 Function Introduction
If rotary cutting machine is selected, the coordinates of Z Axis are shown on the bottom right.
In standby interface, press Enter, and select "Knife / Knife", open the interface for control of
rotary cutting, the start/stop of spindle, ascending / descending of pressure feeding roller, the
switch between the cutting heads and height compensation for head presetting. Select "Knife /
Manual" to manually preset the heads and record the presetting position. Select "Knife /
Automation" to execute the automatic tool setting. Select "Knife / Record Docking Position"
to record the stop position. Select "Knife / Toolsetting Test", open the interface of testing head
presetting position.
