the main interface shows the complete times, speed, power of the file, the speed of jog, and
the position of axis x, axis y, axis z and axis u, etc. The parameters are described below:
Number: the complete times of the selected file.
Speed: the working speed.
Power: the power of Laser 1. The left value is min power value. The right value is the max
power value.
Jog: manually move axis speed, can press the "Select" key to change the speed, there are
"High" or "Slow". The "High" is default Jog speed set by user, and the "Slow" is half of the
Jog Speed.
X, Y, Z/U: the coordinate in the current place in X axis, Y axis, Z axis and U axis.
Notes:
When the Z/U option parameter is set as Z Axis, displays the coordinates of Z axis,
otherwise, it displays U.
When there is no file selected, it displays the default power and speed. When
selecting the file, it shows the power and speed in the first layer of the file. When
processing, it shows the power and speed of the current processed layer.
When the machine is processing, if you want to modify the speed of the current layer,
press the pause button, then press speed button, you can modify the speed of the
current layer. In the same way, press power button to modify the min/max power. If
machine is processing, press "Left/Right" button, can immediately reduce or increase
the laser power. Press once, plus or minus 1%. Left for reduce, Right for increase.
When changed the speed of power during working operation, after the completion of
processing, it prompts whether to save the changes of the speed and power value.
In the standby status, when the processing file is selected, press , and select
"Clear" to clear the number of completions of the current file.
When the machine has autofocus, it can be set through the lifting the U-axis control
platform (or cutting head), and the focal length is set in the laser parameters, press
, and select "Focus" to perform autofocus.
