Shenzhen Topwisdom Technology Co., Ltd
29
1. Protection: in the open state, the system will detect the cover opening protection signal,
and the system will not work in the open state.
2. Protection PN: the connection mode of cover opening protection switch is that the
negative low level is effective and the positive one is high level.
3. Return point: the stop position of laser head after system reset and work. There are three
options: mechanical origin, none and positioning point. If you select "None", the current
position will be stopped after the work is completed.
4. Jog Continue: Open, continuous mode, press and hold the direction key, the axis moves,
release the key, stop the movement; close, it is inching mode, press the key once, the axis
will move the length specified by "inching distance".
5. Jog Step: when the key continuous mode is turned off, set the jog distance of each axis
by pressing the direction key. Unit: mm. 5. Jog distance: when the key continuous mode
is turned off, set the jog distance of each axis by pressing the direction key. Unit: mm.
6. Jog Speed: manual key frame moving speed, unit: mm / s.
7. Return Speed: the speed of the system returning to the origin, unit: mm / s
8. Pulse Time: the time, in MS, of the system to automatically light when the "dot" key is
pressed.
9. Feeding Delay: default time interval of automatic feeding, unit: ms.
10. Min Acc: the corresponding minimum acceleration when starting and stopping. The
smaller the value is, the smaller the start and stop jitter is, and the corresponding
acceleration and deceleration time increases; the larger the value is, the greater the start
and stop jitter is, and the faster the acceleration and deceleration is. Generally, it is
400mm / S2. If faster processing speed is needed, the minimum acceleration should be set
above 850mm / S2. If accurate processing is needed, it should be set to 200mm / S2
(according to the actual machine, here is the recommended value). Unit: mm / S2.
11. Idle Speed: when the default speed is selected for the processing file, the XY axis idle
speed when no light is emitted. Unit: mm / S2.
12. Idle Acc: the acceleration of the XY axis in the absence of light. Unit: mm / S2. The
