Chapter 11
222
UM10349_PCNC1100_Manual_0916A
Diagrams and Parts List
Lower Mill Assembly Parts List
ID PN Description ID PN Description
1 30397 Screw, M6 x 25 33 30428 Pin, 8 x 30
2 30398 Splitter Manifold 34 30429 X- and Y-axis Spacer
3 30399 Machine Base 35 30430 X- and Y-axis Bearing
1
4 30400 Ball Screw Bumper 36 30431 X-axis Ball Screw and Nut
5 30401 Washer 37 32401 X-axis Motor Base
6 30402 Nut, M14 x 1.5 37A 32402 Table Tray (not shown)
7 30403 Screw, M4 x 12 38 30433 Ball Screw Clamp
8 30404 Y-axis Bellows/Spacer 39 31208
Limit Switch Block, X-axis
9 30405 Screw, M6 x 40 40 31209 Screw, M4 x 8
10 30406 Y-axis Bellows Mounting Plate 41 30436 Machine Table
11 30578 Y-axis Bellows Front or Rear 42 30437 Screw, 6 x 26
14 31207 Ball Screw Bumper 43 30438 Washer
15 30411 Screw, M5 x 20 44 30439 Pin, 6 x 25
16 30412 Screw 45 30440 Table Drain Screen
17 30413 Y-axis Gib 46 30441 X Ball Screw Nut Housing
18 30414 Y-axis Saddle 47 30442 Manifold
19 32753 Front Drip Guard 48 30443 X-axis Gib
20 30416 Screw, M5 x 8 49 30444 Sleeve
21 30417 Screw, M5 x 10 50 30445 Y-axis Motor Mount
22 30418
X-axis Motor Mount Cover Plate
51 30446 Ball Screw Bumper
23 30419 Washer 52 31210
X-axis Limit Switch Cover Plate
24 30420 Washer 53 30448 Y-axis Ball Screw and Nut
25 32001 X- and Y-axis Motor 54 30449 Screw, M5 x 25
26 30421 X- and Y-axis Motor Coupling 55 30450 Block
27 30422 Screw, M5 x 16 56 30451 Screw, M5 x 8
28 30423 X and Y Ball Screw Cover Plate 57 30452 Y-axis Limit Switch Housing
29 30424 Washer 58 30453 Y-axis Ball Screw Nut Housing
30 30425 Washer 8 mm 59 31211 X-axis Limit Switch Housing
31 30426 Lock Washer, 8 mm 60 31212 Y-axis Limit Switch Plate
32 30427 Screw, M8 x 40
1
Annular Bearing Engineering Council identication: ABEC7202B Angular Contact (two needed per axis)
