Tormatic B-1200 - Menu 3 + Menu 4: Setting the end positions

56-EN
4.8.1 Preparation
1. Make sure that the garage door is securely engaged in the carriage.
2. Make sure that the antenna is correctly positioned (see section "Routing the
antenna").
3. Make sure that you have all hand transmitters for this garage door at hand.
4. Remove the service flap at the drive head.
5. Connect the mains plug to the mains socket.
ð The point display lights up.
4.8.2 Menu1: Start function for the hand transmitter
D
A1
Fig.9: Programming the start function for the hand transmitter
1. Briefly press the programming button (PROG button)(D).
ð The display shows"1".
2. When the display flashes, press the hand transmitter button with which you
will later start the drive until the point display (A1) on the display flashes
4times.
3. As soon as the light goes out, you can set the next hand transmitter (see
Step1).
NOTICE
Up to 30 codes can be learned.
(Example: 15xstart and 15xlight).
