10
System Values for the Application
System Values
After installing the operator determine the 3 system values. Measure the dimensions
shown in the illustrations below, select each system value listed below the measurement.
Write these numbers down as they are referenced during commissioning.
Door width
System Values
28” 32” 36” 40” 44” 48”
*52” *56” Door width
1 2 3 4 5 6 7 8
Value 1
C
A
A
A
Reveal
0 - 2” 2 - 4” 4 - 6” 6- 8.5” 8.5 - 10.5” 10.5 - 12.5” Distance A
1 2 3 4 5 6 Value 2
Outswing Inswing
11-3/8”
Custom 13-3/4”
A
Custom
B
Lever length C
1 2 3 4 5 6 Value 3
Green LED
Yellow LED
Green LEDYellow LED
Green LED
Yellow LED
Drive Arm
1102
1201
Yellow LED
B
Audible Tone
1
Audible Tone
2
Audible Tone
3
Number of Flashes
Number of Flashes
Number of Flashes
