Tormax 1201 Installation And Service Manual

31
Code Descriptions/ BDM LED Displays
Detecting safety features (optional)
If the safety sensors in the opening and/or closing direction were not detected correctly or
have been connected for the first time, they can be subsequently detected. Detect and save
safety features 1–2
Code 3 on-board configuration (FCP code = 023 )
Procedure according to Code 023 or OB Code 3 Conditions Result
Waiting time 5 seconds (rising motor signal tone).
The safety sensor connection type is detected.
The door opens and closes again.
After the door reaches the open position, the number
of testable safety sensors is indicated by the number of
times the green LED (0–2 times).
Sensors must be
correctly connected.
Do not enter the
detection area of the
moving safety sensors.
If the testing of the safety feature “open” is
success
ful, the door opens at full power.If the
testing of the safety feature “close” is
successful, the door closes at full power.
The safety feature “open” is automatically
suppressed if the door moves against a wall.
Displays
Troubleshooting codes displays as E / H on the user interface. See the Troubleshooting Codes Chart in this manual
for their meaning.
LED displays on the base door module BDM
Yellow LED off OK
Yellow LED on Error (E). See the user interface or Skipper for the error display.
See the Trouble shooting chart in this manual.
Green LED on Power supply and module OK
Green LED off No power supply or power supply overloaded.
Green LED flashes A programming step was started via the on-board programming button.
The process is on going. Press the button briefly to stop the process.
The Green LED flashes
after the open position is
reached
0 × = No testable safety feature available. Door moves with low energy.
1 × = 1 testable safety feature available. Door move
s with low energy.
2 × = 2 testable safety features available. Door moves with full energy.
Procedure according to OB Code 6
Operator rotates 20°, beeps 2x, Press & Release the
OB button, operator will close slowly, automatically
opens slowly & fully open & beeps 2X, close (beep
1x) followed by 5 beeps. and will fully open & close
at normal speed.
Repeat commissioning (without system values)
If the door arm or shaft position was changed or glass was installed in the door after
commissioning.
Code 6 on-board configuration
Conditions
Door travel path un-
obstructed, no physical
contact with the door
during the learn cycles.
Minimal wind load.
Result
Door open & closed positions detected. Door
weight detected.
Safety functions detection according to Code 023,
OB Code 3.
Country Code
The Country code is available in firmware V3.02 and above. The country code provides preset
values to aid the technician in installing the door to comply with ANSI Standard A156.19.
Country code can be set with On-board button Code 7/1 or FCP code 031. To remove the
country code adjustments perform a factory reset. Functions changed are listed below:
Hold Open Time=105 Opening Speed=203 Closing Speed=214
Closing Force=311 Close Check Force=320 Safety Function BDM IN4=602
Safety Function PDM IN4=651 Pair without Overlap=830 Push N Go OFF=860
