Important Information
5
Operator Applications
The 1102/ 1201 are Surface Applied (SA) operators and are power open and spring close.
Basic configuration adjustments will be made with an on-board programming button.
The operator has 2 standard applications:
Outswing - The operator pushes the door open.
Inswing - The operator pulls the door open.
Within each standard application there are important points to know and consider during
the installation process.
Outswing: 8-10 lbs. of manual opening force (Low Energy ANSI A156.19) or Knowing
Act Door Activation (Power Operated Pedestrian Door ANSI A156.10)
18-20 lbs. of manual opening force ( Power Operated Pedestrian Door
ANSI A156.10)
InSwing: 0” reveal, non-handed arm
0“ - 6” reveal, handed arm
Country Code
The Country code is available in firmware V3.02 and above. The country code provides preset
values to aid the technician in installing the door to comply with ANSI Standard A156.19.
This does not eliminate the need for an AAADM inspection to be performed for compliance.
Additional adjustments may need to be made upon inspection.
“U” User mode on FCP
The User mode has two options:
UR - Ability to read specific programming parameters without changing the parameter.
UP - Ability to change programming parameters within a limited range.
Refer to programming table for specifics.
Recommend using “P” programming mode to have full range of adjustments on all parameters.
!
