7
Components Overview
16
17
1
11
14
13
12
1
15
14
2
13
5
6
7
8
9
10
12
1
4
3
Single Door
Double Door
1 Primary drive TORMAX 1102/1201
2 Secondary drive TORMAX 1102/1201
3 Adjustment of spring force TORMAX 1201 only
4 Adjustment of internal open end stop
5 Shaft 2.48 in. (63 mm)
6 Shaft 3.22 in. (82 mm)
7 Shaft 4.84 in. (123 mm)
8 Out-Swing (Push) Arm 11.41/ 13.77 in. (290/350 mm)
9 In-Swing (Sliding Pull) Arm 13.77/ 19.68 in. (350/500 mm)
10 In-Swing (Slide/ Pull) Arm w/Panic 19.68 in. (350 mm)
(not available at this time)
11 Battery unit
12 Header cover
13 Side plate
14 Mounting profile
15 Upgrade modules MDM, PDM, EDM
16 Functional Control Panel (FCP) User interface (Option)
17 On/Off/Hold Open mode of operation switch (Standard)
18 Sync Cable for pairs
19 Shaft retaining bolt
OPEN
AUTO
OFF
18
13
13
19
