Toro 31598N - Lowering the Front-Deck Winglets

2
LoweringtheFront-Deck
Winglets
Partsneededforthisprocedure:
1Rightdeckcover
1
Leftdeckcover
2V-Belt
Procedure
1.Removethenutssecuringthefrontandrearstopbolts
totherightwinglet-deckmounts(Figure3).
Figure3
1.Winglet4.Eccentric
2.Hingepin5.Upperhole
3.Stopbolt
6.Deckmounts
2.Whilesupportingtherightwinglet,removethefront
andrearstopboltsfromthedeckmounts(Figure3).
Note:Leavetheeccentricspositionedbetweenthe
deckmounts.
3.Lowerthewinglettotheoperatingposition.
4.Installthefrontandrearstopboltsthroughthe
upper-mountingholesandeccentrics(Figure4).
Note:Ensurethatthestopboltengagesthetabon
thehingepin.
Figure4
1.Winglet4.Eccentric
2.Hingepin5.Lowerhole
3.Bolt
5.Installthenutssecuringthestopbolts.
Note:Donottightenthenutsatthistime.
6.Repeatthisprocedureonleftwinglet.
7.Installthewingletbeltsasfollows:
A.Startthebeltaroundthewinglet-spindlepulley
andthefront-deck-spindlepulley(Figure5).
Figure5
1.Winglet-spindlepulley3.Idlerpulley
2.Front-deck-spindlepulley
B.Usingaratchetwrenchorasimilartool,movethe
idlerpulleyawayfromthepulleys(Figure5).
C.Routethebeltaroundthewinglet-spindlepulley
andtheupper-spindlepulleyonthefrontdeck.
D.Releasetheidlerpulleytoputtensiononthebelt.
