CleaningtheCabAirFilters
ServiceInterval:Every250hours
1.Removethescrewsandgratesfromboththein-cab
andrearcabairlters(Figure102andFigure103).
1
2
3
g028378
Figure102
In-CabAirFilter
1.Filter
3.Screw
2.Grate
1
2
2
3
g028379
Figure103
RearCabAirFilter
1.Filter
3.Screw
2.Grate
2.Cleantheltersbyblowingclean,oil-free,compressed
airthroughthem.
Important:Ifeitherlterhasahole,tear,orother
damage,replacethelter.
3.Installtheltersandthegratewiththethumbscrews.
CleaningtheAir-Conditioning
Assembly
ServiceInterval:Every250hours(morefrequentlyin
extremelydustyordirtyconditions).
1.Performthepremaintenanceprocedure;referto
PreparingtheMachineforMaintenance(page38).
2.Disconnectthewireforeachfan.
Figure104
Rightfanshown
1.Fan3.Knob
2.Wire
3.Removethe2knobsandremovethefanassembly.
4.Openthe4latchesontheair-conditioningassembly
andremovethescreen.
Figure105
1.Air-conditioningcoil3.Air-conditioningscreen
2.Latch
5.Removetheairlters(seeFigure103).
6.Cleantheair-conditioningassembly.
7.Installtheairlters,screen,andfanassembly(Figure
103,Figure105,andFigure104).
8.Connectthewireforeachfan(Figure104).
