Toro 31598N - Leveling the Front, Center Deck; Leveling the Winglet Decks to the Front, Center Deck

8.Installthewinglet-deckcoverandsecureitwiththe
rubberlatch(Figure6).
Note:Ensurethatyouslidethecoverunderthefront,
centerdeck-covertabsbeforeinsertingitontothe
mountinghooksandpost.
9.Repeatthisprocedureontheotherwinglet.
Figure6
1.Cover
3.Front,centerdeck-cover
tabs
2.Rubberlatch4.Mounthooks
3
LevelingtheFront,Center
Deck
NoPartsRequired
Procedure
RefertoAdjustingtheHeightofCut(page26).
1.Rotatethebladeoneachouterspindleuntiltheends
faceforwardandbackward.
2.Measurefromtheoortothefronttipoftheblade.
3.Adjustthe1/8inchshimsonthefrontcasterfork(s)
tomatchthedesiredheightofcut.
4.Rotatetheblades180°andmeasurefromtheoorto
therear-facingtipoftheblade.
5.Loosenthelowerjamnutsontheheight-of-cutchain
U-bolt.
6.Adjustthenutstoraiseorlowertherearofthemower
decksothatthetipsofthefrontandrearbladeshave
thesamemeasurement.
7.Tightenthejamnuts.
4
LevelingtheWingletDecksto
theFront,CenterDeck
NoPartsRequired
Procedure
1.Rotatethebladeoneachwingletsothatitpointsside
toside.
2.Loosentheboltsandnutssecuringthe2eccentric
spacerstothewinglets(Figure7).
Figure7
1.Winglet4.Eccentric
2.Hingepin5.Upperhole
3.Stopbolt
3.Rotatetherear(closesttothetractionunit)eccentric
untiltheoutsidebladetipisabout3mm(1/8inch)
higherthanthedesiredheightofcut(Figure7).
Note:Thereisanotchontheeccentrichex,whichis
180°fromthelobeontheeccentriccam(Figure8).
Usethenotchestoreferencethelocationofthelobes
whenadjustingtheeccentrics.
15
