Toro 31598N - Cab Controls

Cruise-ControlSwitch
Thecruise-controlswitchsetsyourdesiredspeedofthe
machine.
Presstheswitchforwardtoengagethecruisecontroland
rearwardtodisengageit(Figure10).
AudibleAlarm(Console)
Thealarmisactivatedwhenafaultisdetected.
Thebuzzersoundswhenthefollowingoccur:
•Whentheenginesendsastopfault
•Whentheenginesendsacheck-enginefault
•Whenthefuellevelislow
CabControls
Figure11
1.Air-conditioningswitch4.Temperaturecontrol
2.Air-recirculationcontrol5.Windshield-wiperswitch
3.Fancontrol
6.Blankswitchesforoptional
kits
Air-RecirculationControl
Thiscontroleitherrecirculatestheairinthecabinordraws
outsideairintothecabin(Figure11).
•Setittorecirculatetheairwhenusingairconditioning.
•Setittodrawairinwhenusingtheheaterorfan.
FanControl
Rotatethefan-controlknobtoregulatethespeedofthefan
(Figure11).
TemperatureControl
Rotatethetemperature-controlknobtoregulatetheair
temperatureinthecab(Figure11).
Windshield-WiperSwitch
Usethewindshield-wiperswitchtoturnthewindshield
wiperstotheONorOFFposition(Figure11).
LightsSwitch
Usethelightsswitchtoturntheheadlightsandtail-lightsto
theONorOFFposition(Figure10).
FlashersSwitch
Usetheashersswitchtoturntheashers(hazardlights)to
theONorOFFposition(Figure10).
Air-ConditioningSwitch
Usetheair-conditioningswitchtoturntheairconditioning
onoroff(Figure11).
WindshieldLatch
Liftupthelatchtoopenthewindshield(Figure12).Pressin
thelatchtolockthewindshieldintheopenposition.Pullout
anddownonthelatchtocloseandsecurethewindshield.
Figure12
1.Windshieldlatch
Rear-WindowLatch
Liftupthelatchtoopentherearwindow .Pressinthelatch
tolockthewindowintheopenposition.Pulloutanddown
onthelatchtocloseandsecurethewindow(Figure12).
Important:Youmustclosetherearwindowbefore
openingthehood;otherwise,youmaydamagethe
window.
PowerPoint
Thepowerpoint,locatednexttotheconsoleontheside
ofthepowercenter,isusedtopoweroptionalelectrical
accessories(Figure10).
Seat-AdjustingLever
Pulloutthelevertoslidetheseatforwardorrearward.
18
