Toro 34215 - Operation; Checking the Engine-Oil Level

Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
CheckingtheEngine-OilLevel
ServiceInterval:Beforeeachuseordaily
OilType:Detergentoil(APIserviceSJorhigher)
Oilviscosity:Refertothetablebelow.
Figure17
Important:Donotoperatetheenginewiththeoillevel
belowtheLow(orAdd)markonthedipstick,orover
theFullmark.
1.Movethemachinetoalevelsurface.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position
3.Allowtheenginetocool.
4.Removethedipstickfromtheengineandwipethe
dipstickwithacleanrag(Figure18).
Figure18
1.Dipstick3.Minimumoillevel
2.Maximumoillevel
5.InsertthedipstickfromtheengineasshowninFigure
18.
Note:Donotthreadthedipstickintothellerneck
whencheckingtheengineoillevel.
6.Removethedipstickfromthellerneckandlookat
theoillevelinthedipstick(Figure18).
Note:Theengineoillevelmustcoverbetweenthe
hatchmarkedareasonthedipstick(Figure18).
7.Iftheoillevelislow,wipeofftheareaaroundthe
llerneckandaddthespeciedoiluntiltheoillevelis
betweenthehatchmarkedareasonthedipstick.
Important:Donotoverlltheenginewithoil.
8.Handtightenthedipstickintothellerneck(Figure
18).
20
