Toro 34215 - Jump-Starting the Machine

WARNING
Incorrectbattery-cableroutingcoulddamagethe
machineandcablescausingsparks.Sparkscan
causethebatterygassestoexplode,resultingin
personalinjury.
•Alwaysdisconnectthenegative-batterycable
(black)beforedisconnectingthepositive(red)
cable.
•Alwaysconnectthepositive-batterycable(red)
beforeconnectingthenegative(black)cable.
1.Shutofftheengine,settheparkingbrake,removethe
key,andwaitforallmovingpartstostopbeforeleaving
theoperatingposition.
2.Removethebatterycover(Figure71);refertostep2of
CheckingtheBatteryCharge(page56).
3.Removethehex-angedboltandangednutfromthe
negative-batterycableandnegative(-)batteryterminal,
andremovethecablefromthebattery(Figure73).
Figure73
1.Negative-battery-cable
cover(black)
4.Flangedbolt
2.Flangednut
5.Positive(+)battery
terminal
3.Negative(-)battery
terminal
4.Slidethered-terminalcoveroffthepositive-battery
terminal(Figure73).
5.Removethehex-angedboltandangednutfrom
thepositive(red)batterycableandthepositive(+)
batteryterminal,andremovethecablefromthebattery
(Figure73).
6.Removethebatteryandbatteryboxfromthebattery
trayofthemachine.
InstallingtheBattery
1.Placethebatteryintothebatterybox.
2.Positionthebatteryandbatteryboxontothebattery
trayofthemachine.
3.Installthepositive(red)batterycabletopositive(+)
batteryterminalwithaangedboltandangednut
(Figure73).
4.Slidetheredterminalcoveroverthepositive-battery
terminal.
5.Installthenegativebatterycabletothenegative(-)
batteryterminalwithaangedboltandangednut
(Figure73).
6.Alignthebatterycovertothebatteryboxandsecure
thecoverandboxtothebatterytraywiththebattery
strap(Figure71)
Jump-StartingtheMachine
DANGER
Jump-startingabatterythatiscracked,frozen,has
lowelectrolytelevel,oranopen/shortedbattery
cell,cancauseanexplosionresultinginserious
personalinjury.
Donotjump-startabatteryiftheseconditions
exist;replacethebattery.
CAUTION
Corrosionorlooseconnectionscancauseunwanted
electricalvoltagespikesatanytimeduringthejump
startingprocedure.
Donotattempttojumpstartamachinewithloose
orcorrodedbatteryterminals,ordamagetothe
enginecanoccur.
CAUTION
Connectingthejumpercablesincorrectly(wrong
polarity)canimmediatelydamagetheelectrical
system.
Becertainofthebattery-terminalpolarityand
thejumper-cablepolaritywhenconnectingtothe
battery.
Important:Besurethatthevehiclesdonottouch
andthatbothelectricalsystemsareoffandatthe
sameratedsystemvoltage.Theseinstructionsarefor
negative-groundsystemsonly.
Important:Usetheproperlysizedjumpercables(4to
6AWG)withshortlengthstoreducethevoltagedrop
betweensystems.Ensurethatthecablesarecolorcoded
orlabeledforthecorrectpolarity.
