Toro groundmaster 7210 - Control Panel Overview; Operator Controls Identification

decal106-9290
106-9290
1.Inputs5.Inseat
9.Outputs13.Start
2.Notactive
6.Powertake-off(PTO)10.Powertake-off(PTO)
14.Power
3.Hightemperatureshutdown
7.Parkingbrakeoff11.Start
4.Hightemperaturewarning8.Neutral
12.EnergizetoRun(ETR)
decal120-9195
120–9195
1.Warning—readtheOperator’sManual;donotoperatethe
machineunlessyouaretrained.
8.Warning—wearearprotection.
2.Cutting/dismembermenthazard,mowerblade—keep
bystandersawayfromthemachine;donotcarryany
passengersonthemachine.
9.Disengage
3.Slidingandlossofcontrolhazard;tippinghazard;
drop-offs—donotmowneardrop-offs;keepawayfrom
drop-offs;donotturnathighspeeds;turnatlowspeeds.
10.Engage
4.Tippinghazard—wearaseatbeltwhenaROPSisinplace;
donotwearaseatbeltwhenROPSislowered.
11.Parkingbrake
5.Thrownobjecthazard—keepbystandersawayfromthe
machine;keepdeectorinplace.
12.Starttheengine—1)Cleangrassanddebrisfromthemower
beltandpulleys;2)DisengagethePTO;3)Setthedrivein
neutral;4)Engagetheparkingbrake;5)Turnthekeytopower
onthemower;6)Turnthekeyfullytostarttheengine.
6.Warning—engagetheparkingbrake,stoptheengine,and
removetheignitionkeybeforeleavingthemachine.
13.ReadtheOperator’sManual.
7.Severingoftoesorngers,rotarymowerblade—remove
theignitionkeyandreadtheOperator’sManualbefore
performingmaintenance;keepawayfrommovingparts;keep
allguardsandshieldsinplace.
