Important:Lowertherollbaronlywhen
absolutelynecessary.
1.Tolowertherollbar,removethehairpincotters,
pushtherollbarforwardagainstthesprings,
andremovethe2pins(Figure12).
g004639
Figure12
1.Rollbar3.Hairpincotter
2.Pin
2.Lowertherollbartothedownposition(Figure
13).
g004640
Figure13
1.Pin3.Mountinghole
2.Rollbar
3.Installthe2pinsandsecurethemwiththe
hairpincotters(Figure12).
Important:Ensurethattherearpartofthe
seatissecuredwiththeseatlatch.
4.Toraisetherollbar,removethehairpincotters
andremovethe2pins(Figure12).
5.Raisetherollbartotheuprightpositionand
installthe2pinsandsecurethemwiththe
hairpincotters(Figure12).
Important:Alwaysusetheseatbeltwhenthe
rollbarisintheraisedandlockedposition.Do
notusetheseatbeltwhentherollbarisinthe
loweredposition.
OperatingtheParking
Brake
Alwayssettheparkingbrakewhenyoustopthe
machineorleaveitunattended.
SettingtheParkingBrake
1.Movethemotion-controlleversouttothe
NEUTRAL-LOCKEDposition(Figure18).
2.Pullupandbackontheparking-brakeleverto
settheparkingbrake(Figure14).
Note:Theparking-brakelevershouldstay
rmlyintheengagedposition.
g020868
Figure14
1.Parking-brakelever
WARNING
Theparkingbrakemaynotholdthe
machineparkedonaslopeandcould
causepersonalinjuryorproperty
damage.
Donotparkthemachineonslopes
unlessthewheelsarechockedor
blocked.
