ControlsSystem
Maintenance
AdjustingtheControl-Lever
Neutral-InterlockSwitch
1.Stopthemachine,movethedeck-liftswitch
fullyintotheNEUTRAL-LOCKEDposition,setthe
parkingbrake,andremovetheignitionkey.
2.Removetheboltssecuringthefrontpaneland
removethepanel(Figure80).
g020875
Figure80
1.Bolts
2.Controlpanel
3.Loosenthe2screwssecuringtheinterlock
switch(Figure81).
g004763
Figure81
1.Controllever3.Screw
2.Neutral-interlockswitch
4.0.4to1mm(0.015to
0.045inch)
4.Holdingthecontrolleveragainsttheframe,
movetheswitchtowardtheleveruntilthe
distancebetweenleverandswitchbodyis0.4to
1mm(0.015to0.045inch)asshowninFigure
81.
5.Securetheswitch.
6.Repeatsteps3to5fortheotherlever.
7.Installthefrontpanel.
AdjustingtheControl-Lever
NeutralReturn
Ifthemotion-controlleversdonotalignwiththeneutral
slotswhenyoureleasethemfromthereverse-drive
position,adjustmentisrequired.Adjusteachlever,
spring,androdseparately.
1.DisengagethePTO,movethecontrollever
totheNEUTRAL-LOCKEDposition,andsetthe
parkingbrake.
2.MovethethrottlelevertotheSLOWposition,
stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheboltssecuringthefrontpaneland
removethepanel(Figure82).
62
