WARNING
Theelectricalsystemdoesnotperform
propersafetyshutoffwithjumperwire
installed.
•Removejumperwirefrom
wire-harnessconnectorandplugthe
connectorintotheseatswitchafter
adjustment.
•Neveroperatethisunitwithjumper
installedandseatswitchbypassed.
13.Lowertheseatintoposition.
14.Removethejackstands.
AdjustingtheMaximum
GroundSpeed
1.DisengagethePTO,movethemotion-control
leverstotheNEUTRAL-LOCKEDposition,andset
theparkingbrake.
2.MovethethrottlelevertotheSLOWposition,
stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheboltssecuringthefrontpaneland
removethepanel(Figure86).
g020875
Figure86
1.Bolts
2.Controlpanel
4.Loosenthejamnutonthestopboltforoneof
thecontrollevers(Figure87).
g004766
Figure87
1.Stopbolt
3.Jamnut
2.Controllever4.1.5mm(0.060inch)
5.Threadthestopboltallthewayin(awayfrom
thecontrollever).
6.Pushthecontrolleverallthewayforwarduntilit
stopsandholditthere.
7.Threadthestopboltout(towardthecontrol
lever)untilthereisagapof1.5mm(0.060
inch)betweentheheadofthestopboltandthe
controllever.
8.Tightenthejamnuttosecurethestopboltin
place.
9.Repeatsteps4through8fortheothercontrol
lever.
10.Installthefrontpanel.
Note:Ifyouwishtoreducethemaximummachine
speed,setthespeedforbothcontrolleversas
directedabove,thenbackeachstopboltoutan
equalamounttowardthecontrolleveruntilyoureach
themaximumspeedyoudesire(youlikelyneedto
testyouradjustmentseveraltimes).Ensurethatthe
machinedrivesstraightanddoesnotturnwhenboth
controlleversarepushedallthewayforward.Ifthe
machineturns,thestopboltsarenotevenlysetand
needtobeadjustedfurther.
AdjustingtheTracking
1.DisengagethePTO,movethemotion-control
leverstotheNEUTRAL-LOCKEDpositionandset
theparkingbrake.
2.MovethethrottlelevertotheSLOWposition,
stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingthe
operatingposition.
