Toro MultiPro 1750 - Pre-Maintenance Procedures

NotationforAreasofConcern
Inspectionperformedby:
ItemDate
Information
1
2
3
4
5
6
7
8
9
10
11
12
CAUTION
Ifyouleavethekeyintheignitionswitch,someonecouldaccidentlystarttheengineand
seriouslyinjureyouorotherbystanders.
Removethekeyfromtheignitionanddisconnectthewire(s)fromthesparkplug(s)beforeyou
performanymaintenance.Setthewire(s)asidesothatitdoesnotaccidentallycontactthe
sparkplug(s).
Pre-Maintenance
Procedures
RaisingtheSprayer
Whenevertheengineisrunforroutinemaintenance
and/orenginediagnostics,therearwheelsofthe
sprayershouldbe2.5cm(1inch)offthegroundwith
therearaxlesupportedonjackstands.
DANGER
Asprayeronajackmaybeunstableandslip
offthejack,injuringanyonebeneathit.
•Donotstarttheenginewhilethesprayer
isonajack.
•Alwaysremovethekeyfromtheignition
beforegettingoffthesprayer.
•Blockthetireswhenthesprayerisona
jack.
Thejackingpointatthefrontofthesprayerisunder
thefrontcrossbar(Figure35A).Thejackingpointat
therearofthesprayerisontherearframesupport,
behindthereartie-downloops(Figure35B).
g028108
Figure35
1.Frontjackingpoint2.Reartie-downloops
44
