g002425
Figure49
1.Differential-lockcable3.Spring
2.Transaxlebracket
4.0.25to1.5mm(0.01to
0.06inch)gap
3.Adjustthejamnutstoobtaina0.25to1.5mm
(0.01to0.06inch)gapbetweenthespringhook
andtheoutsidediameteroftheholeinthe
transaxlelever.
4.Tightenthejamnutswhennished.
AdjustingtheFrontWheel
Toe-in
ServiceInterval:Every100hours/Yearly(whichever
comesrst)
Thetoe-inshouldbe0to6mm(0to1/4inch).
1.Fillthetankwithapproximately331L(87.5US
gallons)ofwater.
2.Checkandllalltires;refertoCheckingtheAir
PressureintheTire(page22).
3.Drivethesprayerbackandforthafewtimesto
relaxtheA-arms,thendriveitforwardatleast
3m(10ft).
4.Measurethedistancebetweenbothofthefront
tiresattheaxleheightatboththefrontandrear
ofthefronttires(Figure50).
Note:Youwillneedaxtureoralignment
gaugeformeasuringtherearofthefronttiresat
axleheight.Usethesamextureoralignment
gaugetoaccuratelymeasurethefrontofthe
fronttiresataxleheight(Figure50).
Thefrontofthetiresshouldbe0to6mm(0to
1/4inch)closerthanthebacksideofthefront
tires.
g002006
Figure50
1.Tirecenterline—back4.Fixture
2.Tirecenterline—front
5.Axle-centerlinedistance
3.Axlecenterline
6.15cm(6inches)ruler
5.Ifthemeasurementdoesnotfallwithinthe
speciedrange,loosenthejamnutsatboth
endsofthetierods(Figure51).
g002007
Figure51
1.Jamnut2.Tierod
6.Rotatebothtierodstomovethefrontofthetire
inwardoroutward.
Note:Thetierodsmeasurethesamelength.
7.Tightenthetierodjamnutswhentheadjustment
iscorrect.
8.Ensurethatthereisfulltravelofthesteering
wheelinbothdirections.
54
