Toro MultiPro 1750 - Cleaning the Sprayer Valves

CleaningtheSprayer
Valves
•Tocleantherate-controlvalve,refertothe
followingsections:
1.RemovingtheValveActuator(page62)
2.RemovingtheRate-Control-ManifoldValve
(page63)
3.CleaningtheManifoldValve(page66)
4.AssemblingtheManifoldValve(page67)
5.InstallingtheRateControlManifoldValve
(page68)
6.InstallingtheValveActuator(page71)
•Tocleantheagitationvalve;refertothefollowing
sections:
1.RemovingtheValveActuator(page62)
2.RemovingtheAgitation-ManifoldValve
(page63)
3.CleaningtheManifoldValve(page66)
4.AssemblingtheManifoldValve(page67)
5.InstallingtheAgitation-ManifoldValve(page
68)
6.InstallingtheValveActuator(page71)
•Tocleanthemaster-sectionvalve,refertothe
followingsections:
1.RemovingtheValveActuator(page62)
2.RemovingtheMaster-Section-Manifold
Valve(page64)
3.CleaningtheManifoldValve(page66)
4.AssemblingtheManifoldValve(page67)
5.InstallingtheMaster-Section-ManifoldValve
(page69)
6.InstallingtheValveActuator(page71)
•Tocleanthe3sectionvalves;refertothefollowing
sections:
1.RemovingtheValveActuator(page62)
2.RemovingtheSection-ManifoldValve(page
65)
3.CleaningtheManifoldValve(page66)
4.AssemblingtheManifoldValve(page67)
5.InstallingtheSectionManifoldValve(page
70)
6.InstallingtheValveActuator(page71)
RemovingtheValveActuator
1.Positionthesprayeronalevelsurface,engage
theparkingbrake,shutoffthepump,shutoffthe
engine,andremovethekey.
2.Removethe3-pinconnectorofthevalve
actuatorfromthe3-socketconnectorofthe
sprayerharness.
3.Removetheretainerthatsecurestheactuatorto
themanifoldvalvefortheratecontrol,agitation,
mastersection,orsectionvalve(Figure66).
Note:Squeezethe2legsoftheretainer
togetherwhilepushingitdown.
Note:Retaintheactuatorandretainerfor
installationinInstallingtheValveActuator(page
71).
g028237
Figure66
Section-ValveActuatorShown(theagitation-valveactuator
issimilar)
1.Valveactuator(section
valveshown)
3.Stemport
2.Retainer
4.Removetheactuatorfromthemanifoldvalve.
62
