g028239
Figure75
1.Bypasstting2.Section-valvemanifold
CleaningtheManifoldValve
1.Positionthevalvestemsothatitisintheclosed
position(Figure76B).
g027562
Figure76
1.Valveopen2.Valveclosed
2.Removethe2end-cap-ttingassembliesfrom
eachendofthemanifoldbody(Figure77and
Figure78).
g028243
Figure77
AgitationValveManifold
1.Stemretainer7.BackseatingO-ring(0.676
x0.07inch)
2.Valvestem8.Valve-seatring
3.Stemport9.Manifoldbody
4.Stem-captureretainer
10.Ballvalve
5.End-captting11.End-cap-ttingassembly
6.End-capsealO-ring
(0.796x0.139inch)
66
