Toro PROLINE 44409 - Deck Replacement; Deck Removal; Deck Installation

DeckReplacement
DeckRemoval
1.Parkthemachineonalevelsurfaceandsettheparkingbrake.Stopthe
engine,waitforallmovingpartstostopandremovethekey.
2.Disconnectthebatterybyremovingthenegativebatterycablerst,then
thepositivecablefromthebattery.
3.Placeblocksunderthedeck.
4.Removetheheight-adjustment-pinandlowerthedecktorestontheblocks.
Note:Tensionneedstoberelievedfromthechains.
5.Removethemowerdeckbelt.
6.Removethe4bolts(2boltsperside)onthechainconnectingthedeckstrut
anddeck.
g311250
Figure91
7.Removethe2boltsandfastenersconnectingthedeckstrutanddeckshell.
8.Raisetheheight-of-cuttothetransportposition.
9.Slidethedeckoutfromunderneaththemachine.
DeckInstallation
1.Slidethedeckintopositionunderneaththemachine.
2.Lowertheheight-of-cuttothelowestHOCposition.
3.Installthe2boltsandfastenersconnectingthedeckstrutanddeckshell.
Torqueboltsto40.6N•m(30±3ft-lb).
