WheelandTireAssemblyInstallation(continued)
3.Tightenthelugnutsonthewheel.Torquelugnutsto108N•m(80±10ft-lb).
TransmissionOilFilterReplacement
TransmissionOilFilterRemoval
1.Parkthemachineonalevelsurfaceandsettheparkingbrake.Stopthe
engine,waitforallmovingpartstostopandremovethekey.
2.Loosenthelugnutsonthewheel.
g312499
Figure106
3.Usinganappropriateliftingdevice,raisetherearofthemachineofftheoor.
4.Removethewheelfromthemachine.
5.Removethe2boltssecuringthetransmissionguardtothemachine.
g312500
Figure107
DriveSystem:ServiceandRepairs
Page8–12
PROLINE®ServiceManual
3431-988RevA
