IgnitionSwitchRemoval(continued)
5.Removetheignitionswitchfromthecontroltower.
g312530
Figure116
IgnitionSwitchTest
1.Removetheignitionswitchfromthecontroltower.
2.Usingadigitalmulti-metersettotheOHMorcontinuitysetting,verifythat
continuityexistsbetweentheterminalslistedforeachswitchposition.
3.Usingadigitalmulti-metersettotheOHMorcontinuitysetting,verifythatno
continuityexistsbetweentheterminalsnotlistedforeachswitchposition.
Position
Circuit“Make”
OFF
None
RUNB+R+I+A
STARTB+R+I+S
IgnitionSwitchInstallation
1.Placetheignitionswitchintopositiononthecontroltower.
ElectricalSystem:ServiceandRepairs
Page9–8
PROLINE®ServiceManual
3431-988RevA
