Toro PROLINE 44409 - Transmission Installation

TransmissionInstallation
WARNING
Heavyobject,toavoidmusclestrainorbackinjury,useliftingaids
andproperliftingtechniqueswhenremovingorreplacingheavy
objects.
1.Usinganappropriateliftingdevice,raisethetransmissionuntilableto
connectthetransmissionreservoirhosetothetopofthetransmission.
Continuetoraisethetransmissionintopositiononthemachine.
2.DONOTuseimpacttoolsforboltsonthecrossmember.ReapplyLoctite.
Installtheboltsecuringthecrossmembertobothhydros.Torqueto61N•
m(43±5ft-lb).
Note:Ifinstallingoneorbothtransmissionssimultaneouslyusethefollowing
hydrotighteningsequence:
•Crossshaftbetweenthetransmissions
•Rearmountingnut
•Axlehornnuts
•FrontMountingnut
3.Tightenthe4mountingboltssecuringthetransmissiontotheframe.
g312502
Figure100
4.Installthedrivebelttothefanpulleyontheinputshaft.
DriveSystem:ServiceandRepairs
Page8–8
PROLINE®ServiceManual
3431-988RevA
