Toro PROLINE 44409 - Hydrostatic Drive Belt Replacement; Wheel and Tire Assembly Replacement

HydrostaticDriveBeltReplacement
HydrostaticDriveBeltRemoval
1.Parkthemachineonalevelsurfaceandsettheparkingbrake.Stopthe
engine,waitforallmovingpartstostopandremovethekey.
2.RemovethePTObeltfromthePTOclutch.
3.RemovethePTOclutchfromthecrankshaft.
4.Inserta3/8inchratchetwiththeextensioninthesquareholeinthetensioner
idlerarm.Rotatetoreleasetension.
5.Removethehydrostaticdrivebelt.
HydrostaticDriveBeltInstallation
1.Installthehydrostaticdrivebeltontothemachine.
2.Inserta3/8inchratchetwiththeextensioninthesquareholeinthetensioner
idlerarm.Rotatetoreleasetension.
3.InstallthePTOclutchtothecrankshaft.
4.InstallthePTObelttothePTOclutch.
WheelandTireAssemblyReplacement
WheelandTireAssemblyRemoval
1.Parkthemachineonalevelsurfaceandsettheparkingbrake.Stopthe
engine,waitforallmovingpartstostopandremovethekey.
2.Loosenthelugnutsonthewheel.
g312499
Figure105
3.Usinganappropriateliftingdevice,raisetherearofthemachineofftheoor.
4.Removethewheelfromthemachine.
WheelandTireAssemblyInstallation
1.Placethewheelintopositiononthemachine.
2.Usinganappropriateliftingdevice,lowertherearofthemachinetotheoor.
PROLINE®ServiceManual
Page8–11
DriveSystem:ServiceandRepairs
3431-988RevA
