TransmissionRemoval(continued)

g312502

Figure98

15.Removetheboltsecuringthecrossmembertobothtransmissions.

g312503

Figure99

WARNING

Heavyobject,toavoidmusclestrainorbackinjury,useliftingaids

andproperliftingtechniqueswhenremovingorreplacingheavy

objects.

16.Usinganappropriateliftingdevice,lowerthetransmissionafewinches.

Disconnectthetransmissionreservoirhosefromthetopofthetransmission.

Continueloweringthetransmissiontotheoor.

Note:Useapantocatchuidfromthetransmissionreservoirhosewhen

removing.

PROLINE®ServiceManual

Page8–7

DriveSystem:ServiceandRepairs

3431-988RevA
