ControlsAsm4(36InchInternational)
g312345
Figure62
1.Damper
8.ChokeCable
2.ReferenceBarAsm9.CoverPlate
3.RHControlHandleAsm10.RHControlRodAsm
4.Cam
11.TowerAsm
5.BailSwitch12.ThrottleControl
6.PlateSpeedLimiter13.LHControlRodAsm
7.LHControlHandleAsm
Controls:ServiceandRepairs
Page6–6
PROLINE®ServiceManual
3431-988RevA
