Toro Workman HDX-D - Raising the Cargo Bed in an Emergency

Changing the High-Flow Hydraulic
Fluid and Filter
TC Models Only
Service Interval : Every 1,000 hours —If you are
using the recommended hydraulic
uid, replace the high-ow hydraulic
lter .
Every 2,000 hours —If you are using the
recommended hydraulic uid, change the
high-ow hydraulic uid.
Every 800 hours —If you are not using the
recommended hydraulic uid or have ever lled
the reservoir with an alternative uid, replace
the high-ow hydraulic uid and lter .
Hydraulic uid capacity: approximately 15 L (4 US
gallons)
1. Park the machine on a level surface.
2. Engage the parking brake.
3. Shut of f the engine and remove the key .
4. Clean the area around the high-ow-lter
mounting area ( Figure 69 ).
5. Place a drain pan under the lter and remove
the lter .
Note: If the uid is not going to be drained,
disconnect and plug the hydraulic line going to
the lter .
6. Lubricate the new lter-sealing gasket and hand
turn the lter onto the lter head until the gasket
contacts the lter head. Then tighten it 3/4 turn
further . The lter should now be sealed.
7. Fill the hydraulic reservoir with approximately 15
L (4 US gallons) of hydraulic uid.
8. Start the machine and run it at idle for about 2
minutes to circulate the uid and remove any air
trapped in the system.
9. Stop the machine and check the uid level.
10. V erify the uid level.
1 1. Dispose of the uid properly .
Raising the Cargo Bed in
an Emergency
The cargo bed can be raised in an emergency without
starting the engine by cranking starter or by jumping
the hydraulic system.
Raising the Cargo Bed using the
Starter
Crank the starter while holding the lift lever in the
Raise position. Run the starter for 10 seconds, then
wait 60 seconds before engaging the starter again.
If the engine does not crank, you must remove the
load and bed (attachment) to service the engine or
transaxle.
Raising the Cargo Bed by Jumping
the Hydraulic System
CAUTION
A raised bed full of material without the proper
safety support rod may lower unexpectedly .
W orking under an unsupported raised bed
may cause injury to you or others.
• Before servicing or making adjustments to
the machine, park the machine on a level
surface, engage the parking brake, shut off
the engine, and remove the key .
• Remove any load material from the bed
or other attachment and insert the safety
support on a fully extended cylinder rod
before working under a raised bed.
Y ou will need 2 hydraulic hoses, each with a male
and female quick coupler , that t the machine
couplers, to perform this operation.
1. Back another machine up to the rear of the
disabled machine.
Important: The machine hydraulic system
uses Dexron III A TF . T o avoid system
contamination, make sure that the machine
used to jump the hydraulic system uses an
equivalent uid.
2. On both machine, disconnect the 2 quick-coupler
hoses from the hoses secured to the coupler
bracket ( Figure 71 ).
