Toro Workman MDX-D - Chapter 6 Chassis; General Information 6

Workman MDX--D Page 6 -- 1 Chassis
Chapter 6
Chassis
Table of Contents
SPECIFICATIONS 2............................
GENERAL INFORMATION 3.....................
Operator ’s Manual 3..........................
SPECIAL TOOLS 4.............................
TROUBLESHOOTING 5.........................
Suspension and Steering 5....................
Brakes 6.....................................
ADJUSTMENTS 8..............................
Adjust Parking Brake 8........................
Adjust Front Wheel Camber 9..................
Adjust Front Wheel Toe--in 10..................
SERVICE AND REPAIRS 11......................
Check Tire Pressure 11.........................
Inspect Tires and Wheels 11....................
Upper Steering 12............................
Steering Gearbox 14..........................
Lower Steering and Front Wheels 16............
Front Shock Absorbers 19.....................
A--arms and Front Suspension 20...............
Frame Pivot Yoke 22..........................
Swing Arm 24................................
Parking Brake 28.............................
Rear Wheels and Brakes 30....................
Rear Brake Service 32........................
Front Brake Calipers 34.......................
Front Brake Caliper Service 36.................
Brake Master Cylinder 38......................
Brake Master Cylinder Service 40...............
Bleed Brake System 41........................
Seat Base 42.................................
Front Hood 44................................
Cargo Box 46................................
