Workman MDX--DPage 6 -- 38Chassis
Brake Master Cylind er
1. Brake master cylinder
2. Cap screw (2 used)
3. Brake pedal
4. Clevis pin
5. Cotter pin
6. Flange head nut (2 used)
7. Pedal frame
8. Front brake line
9. Rear brake line
Figure 29
FRONT
RIGHT
3
1
8
4
5
2
6
7
9
