Workman MDX--DPage 4 -- 10Drive Train
Service and Repairs
Drive Clutch
1. Engine
2. Clutch adapter
3. Cap screw (5 used)
4. Drive belt
5. Drive clutch
6. Flange washer
7. Cap screw
Figure 7
v
FRONT
RIGHT
17 to 22 ft--lb
(23 to 29 N--m)
Loctite #242
1
2
6
4
7
5
3
