Toro Workman MDX-D Service Manual

Workman MDX--DPage 3 -- 14Diesel Engine
Engine
Figure 12
1. Engine
2. Engine wire harness connector
3. Hex nut
4. Negative battery cable
5. Engine wire harness connector
6. Lock washer
7. Flange head screw (8 used)
8. Hex nut (4 used)
9. Lock washer (4 used)
10. Exhaust header
11. Flange nut (4 used)
12. Cap screw (4 used)
13. Snubbing washer (4 used)
14. Spacer (4 used)
15. Engine mount (4 used)
16. Engine bracket (front shown)
17. Drive belt
FRONT
RIGHT
2
3
6
8
9
10
11
13
5
7
12
14
15
4
1
7
16
17
