Workman MDX--DPage 4 -- 32Drive Train
Transaxle Assembly
1. Assemble input shaft assembly.
1. Ball bearing 2. Input shaft
Figure 38
1
2
IMPORTANT: Make sure to press ball bearing at the
inner race to prevent damaging the ball bearing.
A. Press ball bearing onto the input shaft.
