Workman MDX--DPage 3 -- 8Diesel Engine
Exhaust System
Figure 6
1. Engine
2. Exhaust header
3. Coupler spring (2 used)
4. Flange nut (4 used)
5. Muffler
6. Hex nut (4 used)
7. Exhaust gasket
8. Flange head screw (4 used)
9. Lock washer (4 used)
FRONT
RIGHT
2
3
4
5
1
4
3
8
6
7
9
