Workman MDX--D Page 3 -- 9 Diesel Engine
Exhaust System Removal (Fig. 6)
1. Park machine on a level surface, stop the engine, en-
gage parking brake and remove the key from the ignition
switch.
2. Raise and support cargo bed to access exhaust sys-
tem.
CAUTION
The muffler and exhaust pipe may be hot. To
avoid possible burns, allow the engine and ex-
haust system to cool before working on the muf-
fler.
3. Remove exhaust system components as needed us-
ing Figure 6 as a guide.
Exhaust System Installation (Fig. 6)
1. Make sure the engine is off.
IMPORTANT: If exhaust studs were removed from
engine cylinder head, thoroughly clean threads in
head and apply Loctite #277 (or equivalent) to stud
threads before installing studs into head.
NOTE: Make sure exhaust header flange and engine
exhaust manifold sealing surfaces are free of debris or
damage that may prevent a tight seal.
2. If exhaust gasket (item 7) was removed, place new
exhaust gasket on the engine exhaust manifold.
NOTE: To ensure proper exhaust system sealing,
mount all exhaust system components loosely before
fully tightening any fastener.
3. Assemble all removed exhaust system components
usingFigure6asaguide.
4. After all exhaust components have been assembled,
make sure that all fasteners are properly tightened.
Also, make sure that all electrical wires and control
cables are not contacted by exhaust components.
5. Lower and secure cargo bed.
Diesel
Engine
