Workman MDX--DPage 3 -- 10Diesel Engine
Fuel Tank
1. Seat
2. Fuel tank
3. Fuel hose (to fuel separator)
4. Fuel hose (return from engine)
5. Seat base
6. Web strapping
7. Hex head flange screw (8 used)
8. Flat washer (8 used)
9. Parking brake support
10. Shift bracket
Figure 7
FRONT
RIGHT
6
9
7
5
8
3
4
2
1
10
