Toro Workman MDX-D Service Manual

Workman MDX--DPage 6 -- 36Chassis
Front Brake Caliper Service
1. Bolt (2 used)
2. Caliper body
3. O--ring (4 used)
4. Caliper bracket
5. Square seal (2 used)
6. Piston (2 used)
7. Brake pad (2 used)
8. Caliper anvil
Figure 28
2
3
6
8
1
5
7
4
(37to44N--m)
27 to 33 ft--lb
BAF--12
Assembly
Lube
White
Lithium
Grease
