Workman MDX--DPage 4 -- 18Drive Train
Installation (Fig. 15)
1. Position transaxle assembly under the vehicle swing
arm.
CAUTION
To prevent personal injury, make sure that
transaxle is properly supported as it is installed
into the machine. Transaxle weighs approxi-
mately 73 pounds (33 kg).
IMPORTANT: Take care to not damage the
transaxle, brake hoses, electrical harness, cables or
other parts while raising the transaxle assembly
into the vehicle.
2. Carefully raise transaxle assembly and align it with
swing arm mounting points.
3. Secure the transaxle to the swing arm with four (4)
cap screws ( item 10) and flat washers (item 5).
4. Secure shift cables to transaxle:
A. Position select lever with attached shift cables to
transaxle assembly. Use notes taken before removal
to properly route cables around transaxle.
B. Slide select lever with attached shift cables onto
transaxle selector shaft.
C. Apply Loctite #242 (or equivalent) to threads of
lock nut (item 18). Secure select lever assembly to
the selector shaft with flat washer (item 15) and lock
nut (item 18).
D. Secure both shift cables to the cable bracket with
jam nuts.
E. Secure r--clamp (item 17) with shift cables to skid
plate with cap screw (item 11) and flange nut (item 7).
F. Check shift cable adjustment and make neces-
sary cable adjustments (see Shift Cable Adjustment
in the Adjustments section of this chapter).
5. Install drive belt to the d riven clutch.
6. Install both brake assemblies and wheels to the
transaxle ( see Rear Wheels and Brakes in the Service
and Repairs section of Chapter 6 -- Chassis). Make sure
that brakes are bled and parking brake is adjusted.
7. Lower vehicle to the ground.
8. Make sure transaxle oil level is correct.
9. Lower and secure cargo box.
10.Check brakes for proper operation.
