cv/gate conguration
The CV/gate conguration section lets you customize the output routing, function, scaling, etc. for each of
the CV/gate outputs.
Routing Selects which channel an output should be routed to.
Function Selects if a CV output should send out pitch, velocity, or gate.
Scaling Selects if pitch should be scaled by V/Oct or Hz/V.
Trig Selects if gates should be V-trig (note off: 0v, note on: 5v) or S-trig (note off: 5v, note on: 0v)
cv/gate presets
The CV/gate conguration section also has three presets to quickly switch between different con-
gurations.
2-voice 2 voices with gate, velocity, and pitch on channels 1 and 2.
3- voice 3 voices with gate and pitch on channels 1, 2, and 3.
drum-gates 6 drum gates on different channels (1 to 6).
user A user-dened conguration that is saved in T-1 Cong.
When a preset is selected the CV/gate conguration is instantly overwritten on your T-1.
misc
In the miscellaneous tab, you can set the brightness of the LEDs on the buttons.
It is also possible to change the LED brightness on the T-1. Press and hold [ CTRL ] and turn the ( TEMPO )
knob.
tools
manual rmware update
If your T-1 failed during a rmware update you may need to perform a manual rmware upload.
This can be done by following these steps:
1. Run from the menu bar of T-1 Cong: “Tools” -> “Upload Firmware” -> “Factory Version”.
2. The script will now upload rmware to your T-1, it takes about 2 minutes.
3. NOTE: If automatic port detection fails, follow the on-screen instructions to manually enter the serial
port.
macOS: It will be called something like “/dev/tty.usbmodemXXXXX”
Windows: It will be called something like “COMxx”, select the one with baudrate = 115200 or 460800
erase banks and settings
All banks and settings can be erased from T-1 Cong. This operation can be used as a factory reset or if
one of your saved banks is corrupt, causing the T-1 to crash upon startup.
This can be done by following these steps
